Range: 100 m
Width: 12.5 mm
Height: 3 mm
Length: 19 mm
Antenna: Chip
Protocol: BLE, Bluetooth 4.0
Data Rate: 1 Mb/s
Frequency: 2.44 GHz
Dimensions: 19 mm x 12.5 mm x 3 mm
Sensitivity: - 91 dBm
Output Power: 4 dBm
Interface Type: GPIO, I2C, SPI, UART
Mounting Style: SMD/SMT
Frequency Range: 2.402 GHz to 2.48 GHz
Moisture Sensitive: Yes
Receiver Sensitivity: - 91 dBm
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 1.8 V
Operating Supply Voltage: 1.8 V to 3.6 V
Supply Current Receiving: 8.8 mA
Supply Current Transmitting: 11.6 mA
Maximum Operating Temperature: + 75 C
Minimum Operating Temperature: - 25 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
