Width: 5.1 mm
Height: 4 mm
Length: 7 mm
Fall Time: 100 us
Rise Time: 300 us
Output Type: Photodarlington
Unit Weight: 224.155 mg
Configuration: 1 Channel
Mounting Style: SMD/SMT
Isolation Voltage: 5000 Vrms
Number of Channels: 1 Channel
If - Forward Current: 50 mA
Vf - Forward Voltage: 1.4 V
Vr - Reverse Voltage: 6 V
Current Transfer Ratio: 1000 %
Pd - Power Dissipation: 200 mW
Maximum Collector Current: 150 mA
Current Transfer Ratio - Max: 15000 %
Current Transfer Ratio - Min: 1000 %
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 30 C
Maximum Collector Emitter Voltage: 300 V
Maximum Collector Emitter Saturation Voltage: 1.2 V
