Width: 1.6 mm
Height: 0.5 mm
Length: 1.6 mm
Function: Schmitt Trigger Buffer
Polarity: Non-Inverting
Logic Type: CMOS
Technology: CMOS
Unit Weight: 25 mg
Logic Family: TinyLogic UHS
Mounting Style: SMD/SMT
Input Signal Type: Single-Ended
Quiescent Current: 1 uA
Number of Channels: 3 Channel
Supply Current - Max: 1 uA
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.65 V
Number of Input Lines: 3 Input
Number of Output Lines: 3 Output
Pd - Power Dissipation: 250 mW
Propagation Delay Time: 6.6 ns at 3.3 V, 5.6 ns at 5 V
Low Level Output Current: 32 mA
Operating Supply Current: 10 uA
Operating Supply Voltage: 1.65 V to 5.5 V
High Level Output Current: - 32 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
