Elara R-290
Field of view (H × V): 90° × 20°
Frequency range: 24.075–24.175 GHz ISM Band
RF transmit power: 14 dBm (0.025 W)
Human detection range: 200 m (656 ft)
Vehicle detection range: 400 m (1312 ft)
Target detection speed: 0.2 m/sec
Radar targets: 32
Range resolution: 1.5 m (4.92 ft)
Range accuracy: <1 m (<3.28 ft)
Angular accuracy: 0.6°
Refresh rate: 10 Hz
Coverage area: Human detection 7.6 acres (30,000 m²)
Target information: GPS coordinates, velocity, RCS, range, azimuth angle/direction, heading, course/track, target ID
Supported protocols: AXML, ONVIF, FLIR Nexus SDK, FLIR Nexus CGI
Pan range: ±43°
Tilt range: 30° / −60°
Optional accessories:
421-0067-00: Pole Mount Kit
421-0066-00: Corner Mount Kit
421-0083-00: 180° Dual Radar Wall Mount Kit
4210755: PoE+ Power Supply
ELARA DX-6xx Specifications
Thermal Sensor & Optics
Array format: 640 × 480 pixels
Detector type: Long-life uncooled VOx microbolometer
Pixel pitch: 12 µm
Thermal sensitivity: <50 mK @ 25°C
Thermal frame rate: NTSC 30 Hz, PAL 25 Hz, 8.3 Hz
Fields of view (FOV): 50° × 38°
Focal lengths: 8.7 mm
f/number: f/1.0
E-Zoom: Continuous e-zoom up to 4×
Spectral range: 7.5 µm to 13.5 µm
Focus range: Athermalized, focus-free
Video
Video compression: Thermal 1 channel H.264 & M-JPEG, Visible 2 independent channels H.264 & M-JPEG
Streaming resolution: Thermal QVGA to VGA, Visible VGA to 4K
Thermal image settings: Auto AGC, Dynamic Detail Enhancement (DDE), Brightness, Sharpness, Contrast
Thermal AGC ROI: Default, Presets, User definable
Image uniformity optimization: Automatic Flat Field Correction (FFC)
Visible Light Camera
Sensor type: Full HD 4K, 1/1.8-type CMOS
Lens field of view: HFOV 61.8° to 2.15°, VFOV 36.65° to 1.2°
Focal length: 6.5 mm to 202 mm
Zoom: 31× optical zoom, continuous e-zoom up to 8×
f/number: f/1.55 (wide) to f/4.8 (tele)
Sensitivity: Color 0.25 lux, B/W 0.10 lux (AGC on, 30 fps)
System Integration
Ethernet: 10/100/1000 Mbps
Network APIs: FLIR SDK, FLIR CGI, ONVIF Profile S
Digital I/O: Input 4 sets 5 V 10 kΩ pull-up, Output 2 sets relay output max 130 mA 24 VDC/AC
Audio I/O: Bi-directional audio terminal block
Illumination: Up to 200 m NIR illumination, 6° / 30° / 90°, peak wavelength 850 nm
Wiper: Standard, compatible with washer accessory
Network
Supported protocols: IPv4, HTTP, UPnP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP
Pan/Tilt Performance
Pan angle/speed: Continuous 360°, 0.1° to 90°/sec
Tilt angle/speed: −10° to 190°, 0.1° to 60°/sec
Programmable presets: 256
