General
Detector Type: Long-Life, Uncooled VOx Microbolometer
Dimensions (L x W x H): 285 x 96 x 94 mm/11.1" x 3.8" x 3.7" With sunshield and fully extended mounting arm
Effective Resolution: 76,800 pixels
Focus Range: Athermalized, focus-free
Input Voltage: 12 VDC 24VAC PoE
Power Consumption: 12 VDC: 17 W (maximum with heaters); 24VAC : 13 VA (maximum with heaters); 24VDC : 13 W (maximum with heaters) PoE: 13 W
Environmental
Humidity: 10%-90% relative humidity
IP Rating (dust & water ingress): IP66
Operating Temperature Range: -40°C to 50°C
Regulatory: FCC Part 15 (Subpart B, Class A), CE marked, EN55032, EN55024, RoHS, WEEE
Storage Temperature Range: -20°C to 70°C
Measurement & Analysis
Analytics Features: Region Entrance/Intrusion Detection, Crossover/Fence Trespassing; Auto/Manual Depth Setup, Human and Vehicle Rules, Hand-off target to autonomous PTZ tracking, Tampering Detection
Analytics Management: Web-based configuration and management, Masking of analytic detection areas, adjustable sensitivity, automatic responses, remote I/O control
System Integration
Ethernet: 10/100 Mbps
External Analytics Compatible: Yes
Network APIs: Nexus SDK for comprehensive system control and integration; Nexus CGI for http command interfaces; ONVIF Profile S
Supported Protocols: IPV4, HTTP, Bonjour, UPnP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP
Thermal Camera
Array Format (NTSC): 320 x 240
Image Uniformity Optimization: Automatic Flat Field Correction (FFC) – Thermal and Temporal triggers
Pixel Pitch: 12u
Thermal AGC Region of Interest [ROI]: Default, Presets and User Defined for optimal image quality of subjects of interest
Thermal Image Settings: Auto AGC, Dynamic Detail Enhancement (DDE), Brightness, Sharpness, Contrast
Video & Recording
Composite Video NTSC or PAL: Hybrid system with IP & analog video
Digital Video Compression: Two independent channels of H.264 and MJPEG
Streaming Resolution PAL/NTSC: Native: 320x256
Visible Camera
Field of view (FOV): 12°
f-number: F1.0
Focal Length: 18mm
Sensitivity: <50mK @ 25c F# 1.0
Spectral Range: 8 µm to 14 µm
Video Frame Rate: NTSC: 30 Hz
