Overview
Array Format: 640 × 512, long-life uncooled VOx microbolometer
Effective Resolution: 327,680 pixels (640 × 512)
Pixel Pitch: 17 µm
Thermal Frame Rate: 30 Hz or 9 Hz
FOV: 17° × 14°
F#: 35 mm F/1.1
Spectral Range: 7.5 µm to 13.5 µm
Focus Range: Athermalized, focus-free
Sensitivity: <25 mK at 25°C, f/1.0
Video
Video Compression: Two independent channels of H.265, H.264, and M-JPEG for each sensor
Streaming Resolution: Thermal VGA (640 × 512)
Thermal Image Settings: Auto AGC, Dynamic Detail Enhancement (DDE), Sensitivity settings
Thermal AGC Region of Interest (ROI): Default, presets, and user-definable settings to optimize image quality on subjects of interest
Image Uniformity Optimization: Automatic Flat Field Correction (FFC) with thermal and temporal triggers
System Integration
Ethernet: Yes
External Analytics Compatible: Yes
Network APIs: Nexus, ONVIF Profile S, G, T
Network
Supported Protocols: IPv4, HTTP, HTTPS, UPnP, DNS, NTP, RTSP, TCP, UDP, ICMP, IGMP, DHCP, ARP, IEEE 802.1X
Mechanical
Pan Angle / Speed: Continuous 360°, 0.1° to 60°/sec
Tilt Angle / Speed: 90° to −90°, 0.1° to 30°/sec
Programmable Presets: 256
