Imaging & Optical
4.3 inch Display: 800 x 480 pixels
Auto orientation: Automatic landscape or portrait
Automatic Image Adjustment: Standard or histogram based on the image content
Built_in Digital Camera: 5 Mpixel with LED light
Camera size excl lens [L x W x H]: 167.2 mm × 204.5 mm × 188.3 mm (6.6 in. × 8.0 in. × 7.4 in.)
Camera software updateUsing USB cable or SD card
Color palettesIron, Rainbow, Rainbow HC, White hot, Black hot, Arctic, Lava
Detector Pitch: 17 µm
Detector Type: Focal plane array (FPA), uncooled microbolometer
Digital Camera: Field of view adapts to the infrared lens
Digital image enhancement: Adaptive digital noise reduction
Digital Zoom: 1–8× continuous
Display Type: Capacitive touch screen
f number : 1.15
Field of view [FOV]: 28° × 21°
Focal Length: 36 mm (1.42 in.)
Focus: One shot or manual
Image Description: Add short note (stored in the JPEG exif tag)
Image Frequency: 30 Hz
Image Modes: Thermal, thermal MSX, picture in picture, digital camera
Infrared Image: Full color infrared image
IR Resolution: 1024 × 768; up to 3.1 MP with UltraMax
Laser: Activated by a dedicated button
Laser Alignment: Position is automatically displayed on the infrared image
Lens Identification: Automatic
Manual Image Adjustment: Linear based, possible to adjust level/span/max./min.
Minimum Focus Distance: 1.3 m (4.26 ft.)
Minimum IR focus distance: 0.4 m (1.32 ft.)
Minimum IR–visual alignment distance: 0.4 m (1.32 ft.)
Multi Spectral Dynamic Imaging [MSX]: Thermal image with enhanced detail presentation
Non_Radiometric IR Video: H.264 to memory card
Non_radiometric IR video recording: H.264 to the memory card
Non_radiometric IR video streaming: H.264 video using Wi-Fi H.264 video using USB
Picture_in_Picture: Resizable and movable infrared area on the visual image
Radiometric IR Video: Real-time radiometric recording (RTRR) to memory card
Radiometric IR video recording: Real-time radiometric recording (RTRR) to the memory card
Radiometric IR video streaming: Real-time radiometric streaming (RTRS) via USB
Sketch: Draw on the thermal/digital image or add predefined stamps Separate PC software with extensive report generation
Spatial resolution [IFOV: 0.47 mrad
Spectral Range: 7.5 - 14 µm
Thermal Sensitivity_NETD: <20 mK @ +30°C (+86°F)
UltraMax: Yes
UltraMax Supported: Yes
Video Lamp: Built-in LED light
Viewfinder: Built-in 800 × 480 pixels
Visual Image: Full color visual image
Visual Video Recording: H.264 to the memory card
Visual Video Streaming: H.264 video using Wi-Fi H.264 video using USB
Measurement & Analysis
Accuracy [Drift] in Screen EST Mode: Accuracy (drift): ±0.3°C (±0.5°F)
Area: 5 + 5 areas (boxes and circles) with max./min./average
Atmospheric transmission correction: Automatic, based on the inputs for distance, atmospheric temperature, and relative humidity
Color alarm [isotherm]: Above/below/interval
Difference Temperature: Delta temperature between the measurement functions and the reference temperature
Emissivity Correction: Variable from 0.01 to 1.0 or selected from the materials list
External Optics and Windows Correction: Automatic, based on the inputs of the window transmission and temperature
Measurement CorrectionsEmissivity, reflected temperature, relative humidity, atmospheric temperature, object distance, external infrared window compensation
Measurement Function Alarm: Audible/visual alarms (above/below) on any selected measurement function
Measurement Presets: No measurements, Center spot, Hot spot, Cold spot, User preset 1, User preset 2
Object Temperature Range: -40°C to 2000°C (-40°F to 3632°F)
Object temperature range Accuracy: ±1°C (±1.8°F) or ±1% at 25°C for temperatures between 5°C to 150°C ±2°C (±3.6°F) or ±2% of reading at 25°C for temperatures up to 1200°C
Optics Transmission Correction: Automatic, based on signals from internal sensors
Profile1 line profile with max./min. temperature
Reference Temperature: Manually set using the difference temperature
Reflected apparent temperature correction: Automatic, based on the input of the reflected temperature
Sampling Average in Screen EST Mode: Recommended temperature range: 30 to 45°C (86 to 113°F) in stable room temperature
Set_up CommandsDefine user presets, Save options, Programmable button, Reset options, Set up camera, Wi-Fi, GPS & compass, Bluetooth, Language, Time & units, Camera information
Spot Meter: 10
Thermal Sensitivity: <0.02°C at +30°C
User Presets: The user can select and combine measurements from any number of spots/boxes/circles/profiles/delta
User Interface
Display: Built-in touch screen, 4.3 in. wide screen LCD, 800 × 480 pixels
Languages: Arabic, Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Russian, simplified Chinese, Swedish, traditional Chinese, Turkish
Text: Add table, select between predefined templates
Touch Screen: Yes
Voice: 60 seconds (via Bluetooth) stored with the image
Power
Battery operating time: >2.5 hours at 25°C (+68°F) and typical use
Battery Type: Rechargeable Li ion battery
Charging systemIn camera (AC adapter or 12 V from a vehicle) or two-bay charger
Charging Temperature: 0°C to 45°C (32°F to 113°F), except for the Korean market: 10°C to 45°C (50°F to 113°F)
Charging Time: 2.5 hours to 90% capacity, charging status indicated by LEDs
External Power Operation: AC adapter 90–260 V AC, 50/60 Hz or 12 V from a vehicle (cable with a standard plug, optional)
Power Management: Automatic power-off functionality, user configurable between 5 minutes, 20 minutes, and no automatic shutdown
