Battery Strings: Up to 4 CG-ELS+ Sensor strings containing 2, 4, 6, and 8 Volt batteries
Input Configurations: Flexible Configuration, typically 24, 48, 110/120, 220/240 and 480 Volt systems
ELS+ Sensor Arrangement:
600 CG-ELS+ Sensors per CG-ELS+ HUB with 150 maximum
CG-ELS+ Sensors for each of the 4 CG-ELS+ HUB inputs
Multiple CG-ELS+ HUB Inputs can be used on a single battery string to monitor all the cells within the battery string
Alarm Output: 2 Form C Dry Contacts, 1A, Duplicate connector pins for alarm aggregation from multiple Hub units
LED Status Indicator: Green (normal state), Red (alarm state)
Power Input: 120V/240V AC 50/60 Hz AC Wall Adapter to 12 VDC at 2 Amps max
Power Status LED: Green when module power is on
Operating Temperature Range: -10 to 65° C
Storage Temperature Range: -20 to 70° C
Dimensions: 3.972” W x 2.023” D x 0.876” H (100.9 mm W x 51.40 mm D x 22.25 mm H)
Enclosure: 94V-0 ABS Plastic Housing
Mounting: Cable Tie Brackets or Free Standing
