Flow Measurement
Flow ranges (all available with x10 range)
0 to 20 ml/min, 0 to 200 ml/min, 0 to 2 litres/min, 0 to 6 litres/min,
0 to 10 litres/min, 0 to 20 litres/min, 0 to 30 litres/min, 0 to 100 litres/min,
0 to 200 litres/min, 0 to 2000 litres/min, 0 to 5000 litres/min
Accuracy @ 20°C
10% to 100% range: < ± (1% reading + 1 digit)
0 to 10% range: < ± (0.1% range + 1 digit)
For dual range instruments, “range” refers to the selected range.
Resolution: 4 digit display
Temperature Coefficients: Zero: Automatic Zero facility, Span: < 0.1% per °C
Long Term Drift (span) < 1% per year
Pressure Measurement
Pressure Ranges:
± 2 mbar, ± 20 mbar, ± 50 mbar, ± 200 mbar, ± 400 mbar, ± 999 mbar
-1 bar to +4 bar, -1 bar to +6 bar, -1 bar to +8 bar, -1 bar to +9.999 bar, -1 bar to +14 bar
Accuracy @ 20°C
10% to 100% range: < ± (1% reading + 1 digit)
0 to 10% range: < ± (0.1% range + 1 digit)
Resolution: 4 digit display
Temperature Coefficients
Zero: < 0.05% per °C
Span: < 0.1% per °C
Long Term Drift (span): < 1% per year
Electrical
Supply Voltage: 24 VDC ± 10% < 1A
Electrical connections
Power: 2 way detachable screw terminal
Outputs: 20 way detachable screw terminal
Inputs: 16 way detachable screw terminal
RS232: 9 pin D plug
RS485: 5 pin detachable screw terminal
LAN: RJ45 connector, 10base-T/100base-TX Ethernet
USB: 1 x USB Type A connector, 1 x USB Type B connector
Control Inputs: Up to 24 Opto-isolated, active high or active low. 5 VDC to 24 VDC into 10 K
Control Outputs: Up to 32 Active High transistor output (PNP). 12 VDC to 45 VDC, 120 mA (per channel)
Pneumatic
Media Compatibility: Clean dry air or non-corrosive gas
Gas Temperature at LFE: 0 – 50°C
Relative Humidity of Gas: 0 – 95% Non-condensing
Air Supply Pressure: Maximum 10 bar gauge, Minimum 5 bar gauge
Regulator Supply Pressure: Maximum 16 bar gauge
Pneumatic Connections
Air supply – 6 mm push-in tube connector
Regulator supply and output – 8 mm push-in tube connector
Up to 5 programmable pneumatic outputs - 4 mm push-in tube connectors
Pressure sense port - 4 mm push-on tube connectors
Laminar Flow Element ports – Size dependent on range:
20, 200 ml/min: 6/4mm Push-on tube fitting
2, 6, 10, 20, 30 litres/min: 12mm Plain Spigot
100 litres/min: 22mm Plain Spigot
200 litres/min: 28mm Plain Spigot
2000, 5000 litres/min: 76mm i/d 184mm o/d flange.
LFE Operating pressure: Maximum static pressure 4 bar.
Construction
Enclosure: Steel construction enclosure with paint finish. Suitable for 19” 3U rack mounting.
Dimensions – Rack Case: 482 x 133 x 296 mm (W x H x D) (excluding LFE)
Dimensions – Bench Case: 366 x 147 x 296 mm (W x H x D) (excluding LFE)
Weight: 8 kg ± 0.5 kg (excluding LFE)
