Direct access to our certified experts
Output Method: HDMI + LAN Port
Resolution: 3840 × 2160
Effective Pixels: 8 Megapixels
Frame Rate: 60 frames/second
Measurement Methods:
Measurement via HDMI-connected monitor
Measurement via PC software
Measurement Accuracy: 0.001 mm
Measurement Units: mm, μm, mil, inch (4 switchable units)
Storage Methods: USB flash drive + PC software storage
Display Languages: Simplified Chinese / English (switchable)
Processor: ARM Cortex-A17 quad-core @ Max. 1.4GHz main processor
Optical Sensor Size: 1/1.7"
Pixel Size: 1.85 μm x 1.85 μm
Memory: 2GB DDR3
Operating System: Custom-developed measurement system based on Linux 3.1
Measurement Tools: Length, angle, arc, circle, polygon, polyline, center-to-center distance, rectangle, annotation, auto edge detection, scale bar, etc.
Image Naming: Automatic or manual naming available
Metallurgical Objective Lenses
Long working distance, plan achromatic metallurgical objective lenses:
5X LMPL5X/0.13 WD15.5 mm ×1
10X LMPL10X/0.25 WD8.7 mm ×1
20X LMPL20X/0.40 WD8.8 mm ×1
50X LMPL50X/0.60 WD5.1 mm ×1
Optical Magnification: 4 levels: 50X, 100X, 200X, 500X (adjustable)
Digital Magnification (Approx.): 4 levels: 100X, 200X, 400X, 1000X [Can be upgraded to 200–2000X]
Viewing Head: 30° inclined, hinged trinocular viewing tube, 360° rotatable, diopter adjustable
Observation Modes: Bright field / oblique illumination / transmitted light / basic polarization
Illumination System: Reflected and transmitted illumination system, wide voltage range 100–240V, adjustable filament center, continuously adjustable brightness
Stand: Dual-purpose stand for transmitted and reflected light, low-position coaxial coarse & fine focusing mechanism
Coarse travel: 33 mm
Fine focusing precision: 0.002 mm
With locking and limit function
Halogen lamp illumination
Bright field reflected illuminator with variable aperture diaphragm, field diaphragm, and filter switching system
Includes blue filter for reflected illumination
Mechanical Stage:
Double-layer mechanical stage
Stage size: 140 × 132 mm
Travel range (X × Y): 76 × 50 mm
With glass stage plate (for transmitted + reflected light)
Light Source:
6V 30W halogen lamp for reflected light
6V 30W halogen lamp for transmitted light
Basic Polarization: φ30 polarizer insertion plate (for reflected light) and 360° rotatable analyzer insertion plate for polarized light observation
Electronic Interface: 0.5X CTV, C-mount, focus adjustable [Optional CTV 1X available]
Eyepiece: High-eyepoint, wide field, plan eyepiece PL10X/18mm (one eyepiece with reticle)
Nosepiece: 4-hole inward-facing, bright-field positioning nosepiece
