Fall Time: 9 ns
Rise Time: 9 ns
Technology: Si
Unit Weight: 750 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Qg - Gate Charge: 170 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 125 W
Vgs - Gate-Source Voltage: - 16 V, + 20 V
Typical Turn-On Delay Time: 19 ns
Typical Turn-Off Delay Time: 46 ns
Id - Continuous Drain Current: 100 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 90 S
Rds On - Drain-Source Resistance: 670 uOhms
Vds - Drain-Source Breakdown Voltage: 25 V
Vgs th - Gate-Source Threshold Voltage: 1 V
