Fall Time: 16 ns
Rise Time: 19 ns
Technology: SiC
Unit Weight: 6 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Qg - Gate Charge: 11 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 44 W
Vgs - Gate-Source Voltage: - 5 V, + 20 V
Typical Turn-On Delay Time: 11 ns
Typical Turn-Off Delay Time: 13 ns
Id - Continuous Drain Current: 5 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 0.76 S
Rds On - Drain-Source Resistance: 1 Ohms
Vds - Drain-Source Breakdown Voltage: 1.7 kV
Vgs th - Gate-Source Threshold Voltage: 4.5 V
