Output Voltage: 50kV
Output Current: 40mA
Duty Cycle: low (<10%)
Input Voltage: For 1kJ/sec 2kW pk operation, a 100-140VDC supply is required.
(However, for 500J/sec 1kW pk, operation from 20-48V is available).
Input Current: Less than 25A maximum
Environment: 0 to 50°C ambient. Non-condensing atmosphere.
Weight: 13kg
Stability, Ripple, etc: maximum PRF of 100Hz.
Control Interface: Active low HV ON input. 0-10V HV and current limit programming,
OC-TTL constant voltage/current outputs, 0-10V HV and current monitor outputs.
