Power rating: 6.4kW
Frequency of operation: 20kHz
Output voltage: 46kVDC on full load
Average current: 140mA max.
Input voltage: 450V peak to peak
Primary current: Quasi sine wave (zero voltage switching)
Leakage inductance: <30uH
Pulse load current: 4A max.
Primary average current: 20A max.
Primary pulse current: 55A max.
Dimensions: 265W x 425D x 347H
Material: Stainless steel
Weight: 50kg max.
High temperature operation: +55°C
High temperature storage: +70°C
Low temperature operation: -20°C
Low temperature storage: -30°C
Relative humidity test: 95% RH at 40°C Non-condensing
