ELECTRICAL PARAMETERS
Accuracy class: 0.02%, 0.05%
Power supply: AC 220 V±10% or 110 V±10%, 50/60Hz
Power consumption: <30VA
Warming-up time: <30min
Voltage measurement
U1, U2,U3: 6.25V, 12.5V, 25V, 50V, 100V, 200V, 400V, 800V (switch automatically), max 1000V
Range: (0-120%)RG
Resolution: 0.01%RG
Accuracy: 0.02%RD or 0.05%RD
Current measurement
I1, I2, I3: 0.25, 0.5, 1, 2.5, 5, 10, 25, 50, 100A(switch automatically)
Range: (0-120%)RG
Resolution: 0.01%RG
Accuracy: 0.02%RD or 0.05%RD
Power measurement
Active accuracy: 0.02%RD or 0.05%RD
Reactive accuracy: 0.05%RD or 0.1%RD
Apparent accuracy: 0.02%RD or 0.05%RD
Energy measurement
Active accuracy: 0.02%RD or 0.05%RD
Reactive accuracy: 0.05%RD or 0.1%RD
Phase measurement
Range: 0.00°-359.99°
Resolution: 0.001°
Accuracy: 0.02° (voltage ≥50V and current ≥250mA)
Frequency measurement
Range: 45-65Hz
Resolution: 0. 001Hz
Accuracy: 0.002Hz
Power factor measurement
Range: -1.0 ~ 0 ~ +1.0
Resolution: 0.0001
Accuracy: 0.0005
Electric energy pulse output
Pulse constant range: 1-2880000000
Output frequency of max. pulse: 600 kHz
Load capacity: >2mA
Default pulse output frequency: 10kHz-600kHz
Energy pulse Input
Input range of pulse constant: 600-700000
Setting range of test pulse: 1-999999999
Max. pulse receiving frequency: 2MHz
Pulse input level: 5V
Voltage/current harmonics measurement
Times: 2-31
Error: 0.05%
Distortion degree error: 0.05%
Transducer measurement
DC voltage range: ±1, ±5, ±10, ±20 V
Accuracy: 0.01%
DC current range: ±1, ±2.5, ±5, ±10, ±20mA
Accuracy: 0.01%
Ripple error: 1%
DC measurements (option)
DC voltage: 50V, 100V, 200V, 400V, 800V (switch automatically), max 1000V
Range: (0 -120%) RG
Resolution: 0.01% RG
Accuracy: 0.02% RD
DC current: 0.1A, 0.3A, 1A, 3A, 10A, 30 A(switch automatically)
Range: (0-120%) RG
Resolution: 0.01% RG
Accuracy: 0.02% RD
MECHANICAL PARAMETERS
Dimensions (W×H×D) (mm): 440×360×160
Weight (kg): 10
ENVIRONMENTAL CONDITIONS
Operating temperature: 10°C ~ 30°C
Relative humidity: ≤85%
