ELECTRICAL PARAMETERS
Rated primary current: 500A AC
Output voltage: 1 mV AC/A
Amplitude accuracy: ±0.3%RD±0.02%FS (10%~100%I1n), 45Hz- 66Hz|Wire centered
Phase accuracy: ±0.5°(10%~100%I1n) (45Hz-5kHZ)
The amplitude frequency characteristic: ±1% (45Hz-5kHZ) (Deviation accuracy)
Conductor impact: ±0.5% (Off-center)
The influence of external lector magnetic fields: ≤0.1A (In AC 400A/m electromagnetic fields)
Maximum input current: 550A AC (Continuous)
(45-66Hz, Ambient temperature 50°C)
Temperature coefficient: ±0.02%/°C of the reading data
Dielectric strength: 5500 V AC rms/Continue 15 seconds (Circuits-iron core, iron core-shell)
The maximum rated voltage: 600V AC rms
Applicable standards: Safety: EN61010-2-032:2012,600V CAT III, Contamination II
EMC: EN61326:1997+A1:1998+A2:2001+A3:2003 (Class A)
MECHANICAL PARAMETERS
Measurable conductor diameter: Max.46mm
Cable length: About 3 m
Dimension (W x H x E): About 96×160×40 (Excluding protruding parts)
Weight: About 395g
ENVIRONMENTAL CONDITIONS
Operating temperature: 0 to 50°C (32-122°F)
Operating humidity: ≤80%RH(No condensate)
Storage temperature: -10 to 60°C (14-140°F)
Storage humidity: ≤80%RH(No condensate)
Operating environment: Indoor, altitude up to 2000 meters
