-Measurement range: 1 mW/cm² to 10 W/cm². Different LED wavelengths and UVA sources
-Typical applications: Monitoring and regulation of LED emitters in UV-A and blue light radiation curing, conveyor belt application, etc.
-Calibration: Irradiance calibration (W/cm²) at specific LED peak wavelengths.
Factory calibration. Traceable to international calibration standards. ISO 17025 calibration on request.
-Spectral responsivity: (350 to 460) nm
-DC: 16 bit
-Housing:
Diameter: 117.6 mm
Height: 12.7 mm
-f2 (directional response/cosine error): <10%
-Data logger: 32000 data points possible with 25 Hz or 2500 Hz
-Display: Graphical LCD with backlight, 128 px x 64 px
-Temperature range: (-10 to 60) °C
-Power Supply:
USB interface (Mini-B): 5 VDC, 500 mA
Lithium polymer battery charged by USB interface
-Battery runtime:
10 hours (backlight on, no operation)
6 hours (backlight on, full operation)
Note: Backlight is automatically switched off during measurements which extends the battery life.
