Clamp opening: 34 mm
Current:
AC 60.00 / 600.0 A rms bei 10 Hz - 3 kHz
DC ±60.00 / ±600.0 / ±900 A dc
AC+DC 60.00 / 600.0 A rms
60.00 / 600.0 / 900 A peak
Inrush current: 6 ..600 A rms / 900 A peak
Voltage:
AC 60.00 / 600.0 / 1000 V rms bei 10 Hz - 3 kHz
DC ±60.00 / ±600.0 / ±1000 V dc
AC+DC 60.00 / 600.0 / 1000 V rms
60.00 / 600.0 / 1400 V peak
Frequency:
f (Uac) 5.0 Hz ..19.99 kHz
f (Iac) 5.0 Hz ..2999 Hz
Power:
Active power: 5999 W / 59.99 / 599.9 / 900 kW
Apparent power: 5999 VA / 59.99 / 599.9 / 900 kVA
Reactive power: 5999 var / 59.99 / 599.9 / 900 kvar
PF -1.00 ..+1.00
Distortion: THDr / THDf 0.0 ..100% / 0.0 ..1000%
Battery: 9 V, IEC 6LF22, 6LR61 or NEDA 1604; > 130 hours (without display illumination)
Additional measurements:
Relative and differential measurements
Temperature in °C/°F via type K thermocouple
Adapter function
Display: 7-segment characters; 6000 digits
Protection: Housing: IP 54, clamp jaws: IP 40
Dimensions H x W x D: 222 x 78 x 42 mm
Weight Approx. 340 g
