Detector
Detector Type: 400×300 @17μm, VOx
Spectral: 8μm～14μm
NETD: ≤50mk
Lens
Focal Length: 25mm/F1.1
Focusing: Manual Focus
FOV: 15.4°×11.6°
Display
Screen: 1280×960 , 0.4 inch，Color LCOS Display (Feel like watching 22 inch screen at 1 meter)
Eyepiece: Monocular, Exit pupil≥10mm, Adjustable diopter-4~＋2
Magnification: 1.7~6.8
Imaging
Frame rate: 50Hz
Digital Zoom: 1X~4X (Smooth zoom)
Color Palettes: White Hot, Black Hot, Iron Red, Blue Hot, Red Hot (TrackIR PRO: Adjustable Red Hot)
Scenes Modes: Enhanced, Highlignt, Natural
Picture-in-Picture: Picture-in-picture enlarged image is displayed on the upper left, upper middle or upper right
Functions
Photo, Video, Hotspot tracking, Stadiametric rangefinder: Yes
Wi-fi/ App: Wi-Fi share photo and video, also can controlled by app（IOS & Android）
Compensation Modes: Auto Compensation / Shutter Compensation / Scene Compensation
Indicate Box: Red,/yellow/green, the coordinates of the indicate box is adjustable
Other: image enhancement, brightness and contrast of image are adjustable, auto power-off, auto sleep, super power-save mode, the work indicator could be shut off
Power supply
Battery Type: Internal Li-ion battery (2x18650, 6000mAh)
Working Time: ≥5h
Weight: 470g
Dimensions: 192×65×71
Package Contents
Standard: Power adapter,USB cable,Micro HDMI cable,Lens cover,Wrist strap, Shoulder strap,Lining package,Quick Start Guide
Optional: External Picatinny rail, External screen and etc…
Interface
USB: TYPE C (USB 2.0 standard ) for charging, data tranmission
Video Output: Micro HDMI
External Connection: External Connection by a Picatinny rail
Memory Card: 16 GB
Environmental Characteristics
Operating Temperature: -10℃～50℃
Storage Temperature: -30℃～60℃
Encapsulation: IP66，1-meter drop test
Certificate: UN38.3 (Battery certificate), RoHS, CE, FCC, EAC
Detection Range
Human: 1.8mx0.5m: 700m
Vehicle: 2.3mx2.3m: 1700m
Recognition Range
Human: 1.8mx0.5m: 350m
Vehicle: 2.3mx2.3m: 700m
