CH1&CH2/ CH3
Output:
Voltage: 0 ~ 60.00V*2/5V,±5%
Current: 0 ~ 3.000A*2/ 5A
Voltage/Current(MAX): 62V, 3.2A
Tracking Series: 0 ~ 120V, 0 ~ 3A
Tracking Parallel: 0 ~ 60V, 0 ~ 6A
Load Regulation:
Voltage: ≤0.01%+5mV, ≤0.02%+5mV (≥10A)/ ≤5mV
Current: ≤0.1%+3mA
Line Regulation
Voltage: ≤0.01%+3mV/ ≤3mV
Current: ≤0.1%+3mA
Ripple & Noise
Constant Voltage: ≤1mVrms (5Hz-1MHz)/ ≤1mVrms(5Hz-1MHz)
Constant Current: ≤2mArms
Setting /Read back Resolution
Voltage(4digits): 20mV
Current(4digits): 1mA
Setting /Read back Accuracy
Voltage: ±(0.1% of reading+30mV) (4digits), ±(0.1% of reading+200mV) (3digits)
Current: ±(0.3% of reading+10mA) (4digits), ±(0.3% of reading+20mA) (3digits)
Recovery Time: ≤100µs (50% load change, minimum load 0.5A)/ ≤100µs
Temperature Coefficient: ≤300ppm/°C
Tracking Operation:
Series Regulation Tracking error:
≤ 0.2% +20mV of Master
(No Load, with load add load regulation ≤200mV)
Line : ≤0.01% + 5mV
Load : ≤ 200mV
Parallel Regulation
Line：≤ 0.01% + 3mV
Load : ≤ 0.01% + 5mV
≤ 0.02% + 5mV ( ≥10A)
Ripple & Noise: ≤2mVrms(5Hz~1MHz)
OVP:
Voltage: OFF,ON (1V ~ 65.0V)/ 5.5V
Resolution: 1V/-
Setting Accuracy: ≤±1V
