Light source:semiconductor laser
Particle size range: 0.8μm~600μm (according to ACFTD calibration 1~100μm or ISO MTD calibration 4~70μm(c) calibration)
Sensitivity: 0.1μm
Custom detection channels: 8~64 channels are optional, and the particle size can be set arbitrarily
Sampling volume: 0.2-6000ml, interval 0.1mL
Sampling accuracy: better than ±1%
Sampling speed: 5-80mL/min
Cleaning speed: 5-80mL/min
Cleaning volume:can be set between 0~90mL
Counting accuracy:the error is less than ±5%
Resolution: ≤10%
Repeatability: RSD＜2%
Limit coincidence error: 12000-40000 grains/mL
Off-line detection viscosity: ≤100cSt (optional pressure chamber if the viscosity is too high))
Pressure range: low pressure 0-0.6Mpa, high pressure up to 42Mpa (optional pressure reducing valve)
Online detection interval time: arbitrary setting
Test sample temperature: 0℃~80℃
Working temperature: -20℃~60℃
Storage temperature: -30℃~80℃
Screen size:7 inches
Power supply: AC100－240V, 50/60Hz
Battery capacity: 5200mAh
Battery running time: 6-8 hours
Dimensions: 310×305×135mm
Instrument weight: 7.5kg
