AC high voltage: AC 700V
AC leakage current IL: 0.01mA~5mA
DC high voltage: DC 1000V
DC leakage current IL: 1 ~ 999uA
Arc detection ARC: 0 ~ 8
Insulation resistance IR: 1MΩ ~ 1GΩ
Short circuit O/S: 200Ω~50KΩ
On-resistance COND: 0.1mΩ~50Ω
Component testing Resistors R: 0.1Ω~1MΩ
Capacitance: 10pF~5000μF
Capacitor polarity: ±
Diode: 0.0V~10V
Reverse current: 1μA~999μA
Test Mode: General circuit/single-side test/point test/single-side point test of on-resistance/sequential test
Measurement method: Series/Parallel
Determination method: Chinese and English voice alarm/speaker
LED / PASS FAIL display
Memory: 128M (about 200 files)
Scanning method: Manual/Continuous/Automatic (Short Circuit Start)
The A and B sides can be set to start sensing separately
Display device 800*480 TFT capacitive screen
Communication interface: USB/RS232/PRINT/HANDER
Work Environment:
Temperature -10 ℃ ~ 40 ℃
Humidity RH ≤ 75%
Power supply: Input 220VAC ±10% 60Hz
Maximum power consumption: 200W
Weight: About 13KG(64p)/14KG(128p)
Chassis size: Width 400mm*Height 260mm*Depth 150mm
