HILO-test CDN 2410 Coupling-/Decoupling Network (1.2/50 µs: 2.5 kV; 5/50 ns: 2.5 kV)

Coupling-/Decoupling Network for I/O lines L1, L2, L3, L4, PE

Nominal voltage AC/DC: 240 V

Nominal current AC/DC: 10 A

max. test voltage Surge, 1.2/50 µs: 2.5 kV

max. test voltage Burst, 5/50 ns: 2.5 kV

Coupling impedance for the surge generator:

0.1 µF / 0.5 µF + 40 Ω

Varistor + 40Ω

Coupling impedance for the burst generator: 33 nF

Coupling mode, selectable, for the surge generator:

line to line via 0.1/0.5 µF or

line to ground via 0.1/0.5 µF

Coupling mode, selectable, for the burst generator: line to ground via 33 nF

Burst Input: Fischer

Surge Input: 4 mm Bush

Mains power: 90V - 264V, 50/60 Hz

Dimensions: desk top case W * H * D 450*180*500 mm3

Weight: 25 kg
