- Rated measurement current: 2000 A AC/DC
- Max. measurement current: 2000 A
(requires derating at frequency))
- Max. allowable peak input: 2840 A peak
- Bandwidth: DC to 10 kHz (-3dB)
- Typical accuracy: ±2.3 deg. (DC < f ≤ 66 Hz)
- Output rate: 0.1 mV/A
- Max. rated voltage to earth: AC/DC 600 V (CAT IV)
- AC/DC 1000 V (CAT III)
- Core diameter: φ 55 mm (2.17 in) or less
- Output connectors: HIOKI PL 14
- Dimensions and mass: 64 mm (2.52 in)W × 195 mm (7.68 in)H × 34 mm (1.34 in)D, 510 g (18.0 oz), Cable length 2.5 m (8.20 ft)
- Accessories: None
