Hioki 3336-02 Power Quality Analyzer (2ch, D/A output)

Name: Hioki 3336-02 Power Quality Analyzer (2ch, D/A output)
Brand: HIOKI

ManufacturerHIOKI

Model3336-02

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

SPECIFICATIONS

- Measurement line type:

+ Single-phase 2-wire, single-phase 3-wire

+ Three-phase 3-wire

- Measurement items:

+ Voltage, Current, Active power, Apparent power, Reactive power

+ Power factor, Phase angle, Frequency, Efficiency

+ Current integration, Active power integration, Integrated time

+ Voltage waveform peak value, Current waveform peak value

+ Voltage crest factor, Current crest factor, Time average current

+ Time average active power, Voltage ripple factor

+ Current ripple factor

- Measurement range:

+ Voltage range: AC/DC 15 V to 1000 V, 7 ranges

+ Current range: AC/DC 200 mA to 50 A, 8 ranges

+ Power range: 3.0000 W to 150.00 kW

- Basic accuracy(Active power):

+ ±0.1% rdg. ±0.1% f.s. (DC)

+ ±0.1% rdg. ±0.05% f.s. (45 Hz to 66 Hz, at Input < 50% f.s.)

+ ±0.15% rdg. (45 Hz to 66 Hz, at 50% f.s. ≤ Input)

- D/A output:

+ 16 channels, Level output DC ±2 V, Waveform output 1 V f.s

+ Level output, instantaneous waveform output(U,I,P)

+ Level output (apparent power, reactive power, power factor, or other)

+ High-speed active power level output

- Other functions:

+ AC+DC, AC+DC Umn, AC, DC, FND, Autorange, Average

+ VT or CT ratio settings, Synchronized control

+ MAX/ MIN, or other functions

- External interfaces:

+ RS-232C

+ LAN standard

- Power supply: 100 to 240 V AC, 50/60 Hz, 40 VA max

- Product Net Weight: 5.6 kg

- Product Size: 305*132*256mm

- Supplied accessories:

+ Instruction manual ×1

+ Measurement guide ×1

+ Power cord ×1

- The warranty period: 12 month

Measurement lines	Single-phase 2-wires, single-phase 3-wires, 3-phase 3-wires, (voltage / current measurement range set for each wiring mode)
Measurement items	Voltage, Current, Active power, Apparent power, Reactive power, Power factor, Phase angle, Frequency, Efficiency, Current integration, Active power integration, Integrated time, Voltage waveform peak value, Current waveform peak value, Voltage crest factor, Current crest factor, Time average current, Time average active power, Voltage ripple factor, Current ripple factor
Harmonic parameters	Synchronization frequency range: 10 Hz to 640 Hz, Analysis order up to 50th Harmonic voltage RMS value, Harmonic current RMS value, Harmonic active power, Total harmonic voltage distortion, Total harmonic current distortion, Voltage fundamental waveform, Current fundamental waveform, Active power fundamental waveform, Apparent power fundamental waveform, Reactive power fundamental waveform, Power factor fundamental waveform (displacement power factor), Voltage current phase difference fundamental waveform, Interchannel voltage fundamental wave phase difference, Interchannel current fundamental wave phase difference, Harmonic voltage content % , Harmonic current content % , Harmonic active power content % (The following parameters can be downloaded as data during PC communication but not displayed: Harmonic voltage phase angle, Harmonic current phase angle, Harmonic voltage current phase difference)
Measurement range	Voltage range: AC/DC 15 V to 1000 V, 7 ranges Current range: AC/DC 200 mA to 50 A, 8 ranges Power range: 3.0000 W to 100.00 kW (Depends on combination of voltage and current range)
Integration measurement (Integration time up to 10,000 hours)	[Current] No.of displayed digits: 6 digits (from 0.00000 mAh, Polarityindependent integration and Sum value) [Active power] No.of displayed digits: 6 digits (from 0.00000 mWh, Polarity-independent integration and Sum value)
Input resistance (50/60 Hz)	Voltage: 2 MΩ, Current: 1 mΩ or less (direct input)
Basic accuracy (Active power)	±0.1% rdg. ±0.1% f.s. (DC) ±0.1% rdg. ±0.05% f.s. (45 Hz to 66 Hz, at Input < 50% f.s.) ±0.15% rdg. (45 Hz to 66 Hz, at 50% f.s. ≤ Input)
Display refresh rate	5 times per second to 20 second (depend on average times settings)
Frequency characteristics	DC, 0.1 Hz to 100 kHz
D/A output (-02/-03 model only)	16 channels (selectable from following items), Level output DC ±2 V, Waveform output 1 V f.s. Level output, instantaneous waveform output (voltage, current, active power) Level output (apparent power, reactive power, power factor, or other) High-speed active power level output
Functions	[Rectification method] AC+DC, AC+DC Umn, AC, DC, FND, Autorange, Average, VT or CT ratio settings, Synchronized control, MAX/ MIN, or other functions
Interface	RS-232C / LAN standard, (-01/-03 model also includes GP-IB)
Power supply	100 to 240 V AC, 50/60 Hz, 40 VA max.
Dimensions and mass	305 mm (12.01 in) W × 132 mm (5.20 in) H × 256 mm (10.08 in) D, 5.2 kg (183.4 oz)
Accessories	Instruction manual ×1, Measurement guide ×1, Power cord ×1

OPTION

CLAMP ON SENSOR 9660

	100A AC rated current, φ 15 mm (0.59 in), 3 m (9.84 ft) length

	Details

CLAMP ON SENSOR 9661

	500A AC rated current, φ 46 mm (1.81 in), 3 m (9.84 ft) length

	Details

FLEXIBLE CLAMP ON SENSOR CT9667

	5000/500 A AC rated current, φ 254 mm (10 in), Cable length: Between sensor - box 2 m (6.56 ft), Output cable 1 m (3.28 ft)

	Details

CLAMP ON SENSOR 9669

	1000A AC rated current, φ 55 mm (2.17 in), 3 m (9.84 ft) length

	Details

				Current measurement [Type 2]

Requires Sensor unit 9555-10 and Connection cord L9217 (1 sensor necessary for single-phase measurement, and 2 sensors required for 3-phase measurements)

AC/DC CURRENT SENSOR CT6865

	CAT III 1000 V, 1000A AC/DC rated current, DC to 20kHz response, core dia. 36 mm (1.42 in), cord length 3 m (9.84 ft)
	Details

AC/DC CURRENT SENSOR 9709

	CAT III 1000 V, 500A AC/DC rated current, DC to 100kHz response, core dia. 36 mm (1.42 in), cord length 3 m (9.84 ft)
	Details

AC/DC CURRENT SENSOR CT6863

	CAT III 1000 V, 200A AC/DC rated current, DC to 500kHz response, core dia. 24 mm (0.94 in), cord length 3 m (9.84 ft)

AC/DC CURRENT SENSOR CT6862

	CAT III 1000 V, 50A AC/ DC rated current, DC to 1MHz response, core dia. 24 mm (0.94 in), cord length 3 m (9.84 ft)

UNIVERSAL CLAMP ON CT 9279

	600 Vrms insulated wire, 500A AC/DC rated current, DC to 20kHz response, core dia. 40 mm (1.57 in), cord length 3 m (9.84 ft), Not CE marked
	Details

UNIVERSAL CLAMP ON CT 9278

	CAT II 600 Vrms, CAT III 300 Vrms, 200A AC/ DC rated current, DC to 100kHz response, core dia. 20 mm (0.79 in), cord length 3 m (9.84 ft)
	Details

UNIVERSAL CLAMP ON CT 9277

	CAT II 600 Vrms, CAT III 300 Vrms, 20A AC/ DC rated current, DC to 100kHz response, core dia. 20 mm (0.79 in), cord length 3 m (9.84 ft)
	Details

CLAMP ON SENSOR 9272-10

	CAT III 600 Vrms, 20A/200A AC rated current, 1Hz to 100kHz response, core dia. 46 mm (1.81 in), cord length 3 m (9.84 ft)
	Details
