Application: used for dynamic and static mechanics performance testing of various steel springs
1: Maximum static test force: ±300kN
2: Distance between columns: 760mm×580mm
3: Available test space: ≥1000mm
4: Up and down space adjustment: Hydraulic lifting and descending
5: Frequency range: 0.5-5Hz
6: Test force indicator precision: ±1%（2%-100%FS）
7: Actuator effective distance: ±150mm
8: Main test wave forms: Sine, triangle, square wave, oblique wave and other programmed waves.
9: Working environment temperature range: 10 ℃—45℃
10: Displacement indicator accuracy: ±1.0%FS
11: Pump specifications: 21Mpa,360L/min，
