Energy(J)
Charpy(ASTM D6110): Five impact energies: 2J, 4J, 5J, 7.5J, 15J, two hammers;
Impact speed(m/s):
Charpy: 2.9,3.8
Maximum friction loss energy: <0.5%
Energy display accuracy: 0.001J (better than 0.05% accuracy)
Pendulum prelift Angle: 150±0.2°
Angle measurement accuracy: 0.001°
Striking center distance
Charpy: 230/395
Izod: 335
American standard ASTM D6110 Charpy test support: 101.6mm
American standard ASTM D6110 notch centering sample: 101.6mm
Charpy specimen type and size (length × width × thickness): 127 mm × 3-12.7 mm × 12.7mm (notch remaining 10.16mm)
American standard ASTM D6110 Charpy impact blade angle and curvature radius: (45±2) degrees (3.17±0.12) mm
Energy unit: J,kJ/㎡,J/m are interchangeable
Power supply: 220VAC-15% ~ 220VAC+10%, 50Hz (single-phase three-wire system)
