Test current: <20mA, 2.5A, 5A, 10A, 20A, 50A
Measuring range:
40μΩ～400mΩ (50A)
100μΩ～1Ω (20A)
500μΩ～2Ω (10A)
1mΩ～4Ω (5A)
2mΩ～8Ω (2.5A)
accuracy：±(0.2%+2word)
10Ω-20KΩ (<20mA)
accuracy：±(0.5%+2word)
Miminimum resolution solution: 0.1μΩ
Indication: liquid crystal display
The resistance shows a valid number of 4 digits
Data storage: 1000 Groups
Work environment:
Ambient temperature: 0℃ ~40℃
Relative humidity: <90% RH, no condensation
Power suply: AC 220V±10V,50Hz±1 Hz
Protective tube 10A
Maximum power dissipation: 1000W
External dimensions:
Main engine：405×230×355(mm)
Wiring box：360×260×180(mm)
Weight:
Main engine: 15.1kg
Wiring box: 5.75KG
Test line length:
Standard configuration 13 metre
Length can be customized
