Specifications
Rated power (KVA/KW): 20/16
Noise level (dBA): 60
Input specification
Nominal voltage (VAC): 380
Input frequency: 380 ± 25%Hz
Connection to generator: supported
Number of phases: 3
Output specification
Voltage (VAC): 220/230/240 ± 0.5%
Frequency (Hz): 50 ± 1%
Transfer time (second): 0 second
Waveform: Standard sine wave
Overload capacity: 127 - 138% in 25-30 seconds
Battery
Quantity and type: Battery cabinet and external battery are not included. 16-32 sealed 12VDC, 60Ah batteries can be set up without maintenance
Dimension & Weight
Product dimensions (mm): 616 x 620 x 500 (L x W x H)
Weight: 248 kg
Operating environment
Operating temperature: 0ºC – 40ºC
Humidity: 20 – 85% without condensation
