Voltage: 80V
Current: 60A
Power: 600W
Min. Operating Voltage: 0.5V@6A/ 1.5V@60A
CV Mode:
Range: 0~8V/ 0~80V
Setting Resolution: 0.1mV/ 1mV
Setting Accuracy (23±5℃): 0.025%+0.025%F.S.
Readback Resolution: 10μV/ 0.1mV
Readback Accuracy (23±5℃): 0.025%+0.025%F.S.
CC Mode:
Range: 0~6A/ 0~60A
Setting Resolution: 0.1mA/ 1mA
Setting Accuracy (23±5℃): 0.05%+0.05%F.S.
Readback Resolution: 10μA/ 0.1mA
Readback Accuracy (23±5℃): 0.05%+0.05%F.S.
CP Mode:
Range: 60W/ 600W
Setting Resolution: 1mW/ 10mW
Setting Accuracy (23±5℃): 0.1%+0.1%F.S.
Readback Resolution: 0.1mW/ 1mW
Readback Accuracy (23±5℃): 0.1%+0.1%F.S.
Range: 1Ω~6kΩ/ 0.1Ω~600Ω
Test Setting Resolution: 0.1Ω/ 0.01Ω
Setting Accuracy (23±5℃): (Vin/Rset)*0.1%+0.1%IF.S.
Slew Rate:
Current: 0.6~600A/ms/ 6~6000A/ms
Power: 0.6~600A/ms/ 6~6000A/ms
Resistance: 0.6~600A/ms/ 6~6000A/ms
Dynamic Mode:
T1&T2: 0.016ms~60000ms/0.016s~60000s
Resolution: 1μs/1ms
Rise/fall slew rate: 0.6~600A/ms/ 6~6000A/ms
Others:
Protection Function: OVP/OCP/OPP/OTP/RV
Interface: LAN/RS232
Communication Protocol: Modbus-RTU standard protocol, SCPI standard protocol, TCP/IP protocol
Response Time: ≤5ms
AC Input: Voltage 110/220V AC, frequency 47Hz~63Hz, current ≤0.25A@220V ≤0.5A@110V
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx.5kg
Dimension: 88.0(H)*214.0(W)*363.0(D) mm
