Stirring quantity max. per stirring position (H2O): 100 l
Motor rating input: 186 W
Motor rating output: 136 W
Motor principle: Brushless DC
Speed display: 7 segment LED
Speed range: 0/30 - 1300 rpm
Viscosity max.: 70000 mPas
Output max. at stirring shaft: 136 W
Permissible ON time: 100 %
Torque max. at stirring shaft: 100 Ncm
Speed control: stepless
Setting accuracy speed: 1 ±rpm
Deviation of speed measurement n > 300rpm: 1 ±%
Deviation of speed measurement n < 300rpm: 3 ±rpm
Stirring element fastening: chuck
Chuck range diameter: 0.5 - 10 mm
Hollow shaft, inner diameter: 11 mm
Hollow shaft (push-through - when stopped): yes
Fastening on stand: extension arm
Extension arm diameter: 16 mm
Extension arm length: 220 mm
Speed control: electronic
Nominal torque: 1 Nm
housing material: alu-cast coating / thermoplastic polymer
Dimensions (W x H x D): 86 x 248 x 208 mm
Weight: 4.4 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 42
Voltage: 230 / 115 / 100 V
Frequency: 50/60 Hz
Power input: 186 W
