Stirring quantity max. per stirring position (H2O): 100 l
Motor rating input: 174 W
Motor rating output: 142 W
Motor principleBrushless DC
Speed display: TFT
Speed range: 0/30 - 1300 rpm
Reversible direction of rotation: yes
Intermittent operationyes
Viscosity max.: 70000 mPas
Output max. at stirring shaft: 136 W
Permissible ON time: 100 %
Torque max. at stirring shaft: 100 Ncm
Speed control: stepless
Setting accuracy speed: 1 ±rpm
Deviation of speed measurement n > 300rpm: 1 ±%
Deviation of speed measurement n < 300rpm: 3 ±rpm
Stirring element fastening: chuck
Connection for ext. temperature sensor: PT1000
Temperature display: yes
Chuck range diameter: 0.5 - 10 mm
Hollow shaft, inner diameter: 11 mm
Hollow shaft (push-through - when stopped): yes
Fastening on stand: extension arm
Extension arm diameter: 16 mm
Extension arm length: 220 mm
Torque display: yes
Speed control: electronic
Nominal torque: 1 Nm
Torque measurement: trend
deviation of torque measurement I: 6 ±Ncm
Timer: yes
Timer display: TFT
Time setting range: 1 - 6000 min
Temperature measuring range: -10 - +350 °C
Temperature measurement resolution: 0.1 K
Accuracy of temperature measurement: ±0.5 + tolerance PT1000 (DIN IEC 751 Class A) K
Limit deviation temperature sensor: ≤ ± (0.15 + 0.002xITI) K
housing material: alu-cast coating / thermoplastic polymer
communication distance (depend onbuilding) max.150 m
Dimensions (W x H x D): 86 x 267 x 230 mm
Weight: 4.7 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 40
RS 232 interface: yes
USB interface: yes
Voltage: 230 / 115 / 100 V
Frequency: 50/60 Hz
Power input: 186 W
