Maximum tool diameter (X axis): 320mm
Maximum tool height (Z axis): 350mm
Repeatability
X axis: 2µm
Z axis: 2µm
X/Z axis resolution: 1µm
Camera: Color CCD
Image processing accuracy: 1µm
Magnification: 12X
View field: 7×7mm
Illumination: Adjustable LED light
Spindle: ISO/SK/BT50 (concentricity: 2µm)
Data output: USB, RS232
Working air pressure: 0.6-0.8MPa
Environmental requirement:
Temperature: 5~35°C
Relative humidity: 10%~95%
Power supply: 100-240V, 50/60Hz
Dimension (L×W×H): 1200×400×870mm
Weight: 80kg
