Specification
Optical lens:Ø100mm dual-telecentric lens
Measurement range:100x80mm
Measurement accuracy:
Axial:±(5+L/20)µm
Radial:±(3+D/20)µm
Repeatability:
Axial:±2µm
Radial:±1µm
Illumination system:
Transmission light:telecentric illuminator, green light
Surface light (optional):high angle ring, white light
Max. weight of workpiece:3kg
Measurement time:<2s
Environmental requirement:2D measurement
Measurement data:temperature: 20°C±2°C, relative humidity: 30%-80%, vibration: <0.002g, less than 15Hz
Power supply:220V, 50Hz, 600W
Dimension (LxWxH):790x230x385mm
Weight:27kg
Standard delivery:
Main unit:1pc
Computer:1pc
Software:1pc
