Basic
Sensor: PYTHON 1300
Image Sensor: 1/2"CMOS
Shutter: Global
Resolution: 1280 × 1024
Frame Rate: 60 fps
Bit Depth: 10
Mono/Color: Mono
Pixel Size: 4.8 μm × 4.8 μm
Pixel: 1.3MP
S/N Ratio: >38dB
WDR: 60dB
Image Format: Mono8/10/10Packed
Binning: Support
Decimation: Support
ROI: Support
Gain: 1~32
Gamma: From 0 to 4，support LUT
Exposure Time: 1μS~1S
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
FPN: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 64MB
Port
Port: GigE
GPIO Interface: 1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output
Lens Mount: C-mount
Power
Power Supply: DC 9V~24V power supply via Hirose interface
Power Consumption: 12V≈2.8W
Structure
Product Dimensions: 29mm*29mm*29mm
Net Weight: 60 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
