Basic
Sensor: IMX430
Image Sensor: 1/1.7"CMOS
Shutter: Global
Resolution: 1624 × 1240
Frame Rate: 89 fps
Bit Depth: 12
Mono/Color: Mono
Pixel Size: 4.5 μm × 4.5 μm
Pixel: 2.0 1MP
S/N Ratio: >38dB
WDR: 70dB
Image Format: Mono8/10/10Packed
Binning: Support
ROI: Support
X Flip: Support
Y Flip: Support
Gain: 1~32
Gamma: Range from 0 to 4, support LUT
Exposure Time: 18 μs~1 s
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 64 MB
Port
Port: USB 3.0
GPIO Interface: 6 pin Hirose: 1 Opto-isolated input, 1 Opto-isolated output, 1 configurable input/output without opto isolation
Power
Power Supply: Power supply via USB connector /DC power supply by Hirose connector, with voltage range from 9V to 24V
Power Consumption: ≈3.2 W
Structure
Product Dimensions: 29 mm×29 mm×29 mm(not including rear case connector)
Net Weight: 60 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
