Basic
Sensor: PYTHON2000
Image Sensor: 2/3"CMOS
Shutter: Global
Resolution: 1920 × 1200
Frame Rate: 37.8 fps
Bit Depth: 10
Mono/Color: Color
Pixel Size: 4.8 μm × 4.8 μm
Pixel: 2.3MP
S/N Ratio: >38dB
WDR: 60dB
Image Format: BayerRG8/10
ROI: Support
Y Flip: Support
Gain: 1~32
White Balance: automatic white balance
Exposure Time: 45μS~1S
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
Performance
User Setting: Support two sets of user-defined configurations
Port
Port: CameraLink
GPIO Interface: 1x Opto-isolated input, 1x Opto-isolated output, 1 configurable input and output
Lens Mount: C-mount
Power
Power Supply: PoCL power supply
Power Consumption: 2.34W
Structure
Product Dimensions: 29mm*29mm*43.8mm(not including lens mount and rear case connector)
Net Weight: 80 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
