Basic
Sensor: GMAX3265
Image Sensor: 29.9 mm x 22.4 mm CMOS
Shutter: Global
Resolution: 9344 × 7000
Frame Rate: 1.7 fps
Bit Depth: 12 bit
Mono/Color: Color
Pixel Size: 3.2 μm × 3.2 μm
Pixel: 65 MP
S/N Ratio: 40 dB
WDR: 66 dB
Image Format: Mono8, BayerRG8/10/10Packed/12/12Packed, BayerGB8/10/10Packed/12/12Packed, YUV422 Packed, YUV422_8
ROI: Support
X Flip: Support
Y Flip: Support
Gain: 1 ~ 32
White Balance: Support
Gamma: 0 ~ 4，support LUT
Exposure Time: 16 μs ~ 15 s
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 512 MB
Port
Port: GigE
GPIO Interface: 3x Opto-isolated input, 3x Opto-isolated output, 1x RS232 interface
Lens Mount: M58 x 0.75
Power
Power Supply: DC 24V power supply via the 12-pin Hirose interface
Power Consumption: 24 V ≈ 8.4 W
Structure
Product Dimensions: 72 mm x 72 mm x 64.8 mm ( (not including the rear case connector)
Net Weight: 482 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
