Basic
Sensor: 4K
Image Sensor: CMOS
Shutter: Global
Resolution: 4096 × 1
Line Rate: 28 kHz
Bit Depth: 12
Mono/Color: Mono
Pixel Size: 7 μm × 7 μm
S/N Ratio: >38dB
WDR: 66dB
Image Format: Mono8/10/12/10Packed/12Packed
ROI: Support
X Flip: Support
Gain: 1~32
Gamma: From 0 to 4，support LUT
Exposure Time: 8μS~100mS
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
FPN: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 64MB image cache，64MB data cache
Port
Port: GigE
GPIO Interface: 2 differential input, 2 single-end input, 1 differential output and 1 GPIO.
Lens Mount: M42 x 1
Power
Power Supply: DC12~24V power supply via 12-pin Hirose connector
Power Consumption: ≈4.5W
Structure
roduct Dimensions: 62 mm × 62 mm × 35.8 mm (Not including rear case connector)
Net Weight: 240 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
