Basic
Sensor: 8 K
Image Sensor: CMOS
Shutter: Global
Resolution: 8192 × 1
Line Rate: 13 kHz(After compression the line frequency is 58k）
Bit Depth: 12
Mono/Color: Mono
Pixel Size: 7 μm × 7 μm
S/N Ratio: 46dB
Dynamic Range: 65.9 dB
Sensitivity: 77
Image Format: Mono8/10/12/10Packed/12Packed
ROI: Support
X Flip: Support
Gain: 1~32
Gamma: From 0 to 4，support LUT
Exposure Time: 2 μs~100 ms
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
FPN: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 512MB data cache
Port
Port: GigE
GPIO Interface: 2 differential/single-end input, 2 differential/single-end output, 1 differential/single-end configurable input/output and 1 GPIO.
Lens Mount: M72 x 0.75
Power
Power Supply: DC 12~24V power supply via 6-pin Hirose connector
Power Consumption: 12 V ≈ 4.5 W
Structure
Product Dimensions: 80mm*80mm*48mm(Not including rear case connector)
Net Weight: 390 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
