Fall Time: 17 ns
Rise Time: 27 ns
Technology: Si
Unit Weight: 2 g
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 16.7 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 180 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 23 ns
Typical Turn-Off Delay Time: 75 ns
Id - Continuous Drain Current: 14 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 7 S
Rds On - Drain-Source Resistance: 250 mOhms
Vds - Drain-Source Breakdown Voltage: 600 V
Vgs th - Gate-Source Threshold Voltage: 2.5 V
