Working Stage
Metal Stage Size (mm): 408X308
Glass Stage Size (mm): 305.6x197.5
X Y Z axis Travel (mm): 250x150x200
Dimensions (L x W X H) (mm): 776x653x1760
Data Measurement System
Z-Axis Travel: 200 mm (including focus adjustment)
Lens Focal Length: Approx. 92 mm
X, Y, Z Digital Display Resolution: 0.0005 mm
X, Y Coordinate Indication Error: ≤ (3 + L/200) µm
Imaging System:
Camera: 1/3" Color CCD Camera
Zoom Objective Magnification: 0. 7 - 4.5X
Total Video Magnification: 30X - 230X
Object Jfield of View: 7 - 1.1 mm
Surface Light Source & Transmitted Light Source: LED-basedwith adjustable brightness
Power Supply: 180V(AC) -260V (AC) 50Hz
Measurement Software:
Standard software includes automatic edge detection, deburring measurement, and workpiece al igrunent.
It supports measurements of points, 1ines, circles, angles, center distances, and more
