JEIOTECH MS-22B Magnetic Stirrers (150 ~ 2,500 rpm)

Name: JEIOTECH MS-22B Magnetic Stirrers (150 ~ 2,500 rpm)
Brand: JEIOtech

ManufacturerJEIOtech(View more products from this manufacturer)

ModelMS-22B

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Speed Control Electronic speed control
Speed Range (RPM) 150 ~ 2,500
Motor Rating Input / Output (W) 2.9 / 1.6
Load, Max (kg / lbs) 25 kg
Material Poly propylene with non-slip silicon cover
Dimension (mm / inch, W×D×H) 230×230×65 mm
Electrical Requirements AC 100 ~ 240V, 50 / 60Hz with power adapter
Weight (kg / lbs) 1.1 kg
Protection Class (DIN EN 60529) IP42

Ordering information

AAH330315BU: MS-22BB Magnetic Stirrer(Scale, ф220mm, Percian Blue), US Plug

AAH330315BK: MS-22BB Magnetic Stirrer(Scale, ф220mm, Percian Blue), KR Plug

AAH330315YU: MS-22BY Magnetic Stirrer(Scale, ф220mm, Orange), US Plug

AAH330315YK: MS-22BY Magnetic Stirrer(Scale, ф220mm, Orange), KR Plug

Plate Covers, Silicone Pads, Power Adapter

Plate Covers (Black & White)

Features of MS-B, T Models

Best-in-the-class with broad speed range and suitable for high-speed rotation experimental environment.
Ergonomic designed, lightweight, easy to operate, and low profile.
Wide top plate.
Two non-slip silicon plate covers (white & black) provided for all MS-B, T, G Models.
Non-slip strength rubber feet.
Sparkless, silent and durable BLDC motor.
Built-in thermal shutdown and current limit protection.

Model ¹⁾			MS-12B	MS-12T	MS-17B	MS-17T	MS-22B
Technical Data	Speed Control		Electronic speed control
	Stirring Capacity (Liter, H2O)		2		4		5
	Speed Range (RPM)		150 ~ 2,500
	Speed Display		None
	Motor Rating Input / Output (W)		2.9 / 1.6
	Magnetic Bar (Ø×L, mm / Inch), Max.		8×30 / 0.31×1.18	8×30 / 0.31×1.18	8×40 / 0.31×1.57	8×30 / 0.31×1.18	10×50 / 0.39×1.97
	Load, Max (kg / lbs)		15 / 33.07	10 / 22.05	20 / 44.09	20 / 44.09	25 / 55.12
Top Plate	Material		Poly propylene with non-slip silicon cover
Top Plate	Dimension (mm / inch, Ø)		120 / 4.72	115 / 4.53	170 / 6.69	165 / 6.5	220 / 8.66
General Data	Body Material		Poly propylene
	Dimension (mm / inch, W×D×H)		130×130×65 / 5.12×5.12×2.56	181×176×57 / 7.13×6.93×2.24	185×185×65 / 7.28×7.28×2.56	246×243×57 / 9.69×9.57×2.24	230×230×65 / 9.06×9.06×2.56
	Weight (kg / lbs)		0.6 / 1.32		0.9 / 1.98		1.1 / 2.43
	Electrical Requirements		AC 100 ~ 240V, 50 / 60Hz with power adapter				AC 100 ~ 240V, 50 / 60Hz
	Power Consumption (W)		5		6
	Protection Class (DIN EN 60529)		IP42
Cat. No.	Persian Blue	KR plug	AAH330115BK	AAH333115BK	AAH330215BK	AAH333215BK	AAH330315BK
	Persian Blue	US plug	AAH330115BU	AAH33316BU	AAH330215BU	AAH33326BU	AAH330315BU
	Yellow	KR plug	AAH330115YK	-	AAH330215YK	-	AAH330315YK
	Yellow	US plug	AAH330115YU	-	AAH330215YU	-	AAH330315YU
	Orange	KR plug	-	AAH333115RK	-	AAH333215RK	-
	Orange	US plug	-	AAH33316RU	-	AAH33326RU	-

1) B-models: round type, T-models; triangle type.
