Max. Loading (kg): 800
Peek Value Acceleration (m/s): 50~500
Pulse Time (ms): 20~3
Shock Frequency (times /min): 10~80
Bench Size WxD(mm): 1000x1000
Max. Dropped Height (mm): 60
Impact and Crush Wave: Half Sine wave , (trapezoidal wave , and the sawtooth wave, square wave optional)
External Dimension WxHxD (mm): 1000x1300x1900
Weight (Kg): 3500
Protection Device: Door protection, over-load protection, zero signal protection
Power: AC220V; 1∮ 3 lines; 50/60HZ AC380V; 3∮ 5 lines; 50/60HZ
Environmental Conditions: Temperature : 25C±5.0℃; Humidity : <85%R.H.(25°C)
Standard: GB/T2423. 5. 6-1995, IEC68-2-29, JJG497-2000, IEC68-2-27
Control Measure System: Shock DAQ computer control measuring system
