Capacity(L): 1200
Working space Internal Dimension WxHxD (mm): 1050x1000x1150
Without Vibration Tester's Height External Dimension WxHxD(mm): 2250x2100x4350
Dimension of Vibration Shaker's Table: Customize
Temperature Range:
+ High Temperature: 150°C( 200°C is optional)
+ Low Temperature: -60°C
Humidity Range: 20%-98%R.H.(5%, 10%-98% RH special condtional need dehumidifier,Optional)
Analytic Accuracy/ Distribution Uniformity of Temperature and Humidity: 0.1°C; 0.1% R.H/ ±0.2°C; ±0.3% R.H:
Control Accuracy of Temperature: ±0.5°C; ±2.5% R.H
Temperature Rising/Falling Speed Rate: Temperature rising approx:0.1~3.0°C/min; Temperature falling approx: 0.1~1.2°C/min (5°C, 10°C,15°C, 20°C,25°C/min with non-linear control or linear average control-optional)
Pressure range: Atmospheric pressure ~0.5kPa
Pressure time: Atmospheric pressure ~1kPa ≤ 30min
Pressure recovery time: ≤±10kPa/min
Rapid decompression time: 75.2kPa~18.8kPa≤15s(Optional)
Cooling System: Wind cooling or water cooling
Optional Accessories: Inner door with operation Hole, Recorder, Water Purifier, Dehumidifier
Vibration Test Equipment: Choose Vibration tester according to customer's test conditionplease take Vibration Test system's catalog for reference
Structural Style: L-Elevator G-Gantry elevator, F-Fixture type
Power: AC380V,3 phase 5 lines,50/60HZ
