Technical Parameters:
Grinding disc diameter: Standard φ254mm
Grinding disc speed: 100-1000r/min (stepless speed regulation) Four-speed speed regulation 300 500 800 1000r/min
Grinding head speed: 0—120r/min
Grinding disc rotation direction: Two-way forward and reverse
Grinding disc motor power: 2.2KW
Grinding head rotation direction: Clockwise
Grinding head motor power: 0.2KW
Grinding head locking method: Manual (optional automatic)
Timing adjustable time: 0-99min
Pressure method: Central pneumatic pressurization
Pressure adjustment method: Mechanical pressure regulation
Pressure range: 0-0.3Mpa (commonly used 0.05-0.3Mpa)
Specimen clamping specifications: Standard Ф30 (others can be customized)
Number of specimen clamping: 6
Power supply: Voltage: 220V Frequency: 50HZ
Total power: 2.8KW
Overall dimensions: 770 x 730 x 700mm
Wooden box dimensions: 950 x 810 x 810
Weight: 100Kg
Product advantages:
1. The base is made of aluminum alloy material, which is lightweight, has good shock absorption and corrosion resistance.
2. The shell is made of high-end ABS, which is novel in appearance, high-end and classy.
3. Touch screen display control, clear and intuitive interface, easy to operate.
4. It can be timed, fixed speed and fixed pressure.
5. The built-in nozzle sump is automatically cleaned.
6. Infinite speed regulation or four-speed speed regulation, convenient and fast.
7. It can be started in single action or linkage as needed.
8. It can store more than 100 sets of grinding and polishing process formulas for quick call.
9. The magnetic disk design supports fast disk change, and it is more convenient and quick to change sandpaper and polishing fabric.
10. The free rotation design of the sample clamping plate, combined with the inner lighting system, is convenient for taking and placing samples.
11. The grinding head adopts electromagnetic clutch automatic locking, which is convenient and fast. (Optional)
12. The whole machine adopts DC brushless and stepper motors, which rotate smoothly, have low noise and long life.
13. Double-disc design, double-disc dual control, double sample preparation efficiency.
14. Automatic centering to prevent multiple grinding and polishing
