Mass Scope of Workpiece(kg): 500
Max Diameter of Workpiece(mm): Φ1500
Distance Between Two Support Bearings(mm): Min 60
Journal Diameter Scope of Workpiece(mm): Φ15~752)
Max Distance between Driving Flange and Right Bearing Support (mm): 1500
Rotational Speed of the Main Axis(r/min): 600,1095(4)
Motor Power (kw): 4(1)
Torque of Universal Joint Shaft(N·m): 60
Length of Bed (mm): 2500
Min Achievable Residual Unbalance Amount(emar): ≤0.5g· mm/kg
Notes:
1)Frequency conversion
2)Can add to 75-180
3)Can add to 120~240
4)Stepless speed regulation
