Channels: 4 Analog Channels
Bandwidth: 100 MHz
Input impedance: 1 MΩ ± 1% || 11pF
Vertical resolution: 8 bits
Max Sample Rate: 2 GSa/sec
Memory depth: 2 channels/4 channels: 8 Mpts/4 Mpts
Trigger mode: Auto, Normal, Single
Standard ports: USB 2.0 high speed, 10/100-BaseT LAN, IEEE488.2 GPIB, XGA video output
Physical size 43.5 cm W x 27 cm D x 4.2 cm H (without brackets)
Weight Net: 2.45 kg (5.4 lbs.) Shipping: 6.2 kg (13.6 lbs.)
Power: 100-240V, 50/60Hz
