Maximum sampling rate: 100 Msamples/sec, continuous sampling
Video bandwidth: ≥ 30 MHz
Single shot bandwidth: ≥ 30 MHz
Rise time and fall time: ≤ 13 ns (for frequencies ≥ 500 MHz), see Figure 1 (in Datasheet)
Minimum pulse width: 50 ns
Overshoot: ≤ 5%
Average power measurement accuracy
N1921A: ≤ ± 0.2 dB or ± 4.5%
N1922A: ≤ ± 0.3 dB or ± 6.7%
Dynamic range
–35 to +20 dBm (> 500 MHz)
–30 to +20 dBm (50 to 500 MHz)
Maximum pulse repetition rate :10 MHz (based on 10 samples per period)
