Width: 2 mm
Height: 7 mm
Length: 5 mm
LED Size: 5 mm x 2 mm x 7 mm
Lens Color: Colorless
Lens Shape: Rectangular
Unit Weight: 279.866 mg
Power Rating: 75 mW, 62.5 mW
Configuration: Common Cathode
Viewing Angle: 140 deg
Mounting Style: Through Hole
Lens Dimensions: 2 mm x 5 mm
Lens Transparency: Diffused
Illumination Color: Red, Green
Luminous Intensity: 20 mcd, 9 mcd
If - Forward Current: 20 mA
Vf - Forward Voltage: 2 V, 2.2 V
Wavelength/Color Temperature: 617 nm, 568 nm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
